ToppTube™ PA12P40
- Good impact resistance
- Superior in high temperature applications
- High pressure resistance
Applications
- Pneumatics
- Industrial robots
- Instrumentation lines
Specification
Material: Polyamide PA12 (Nylon 12)
Hardness: PA12: Special product, PA12P40: 60 shore D
Installation Temperature: -20 °C…+50 °C
Working Temperature: -40 °C…+80 °C
Operating Pressure: 4,0 bar…135 bar (depending on tube dimensions and temperature).
Tolerances: According to DIN 74324.
Colours: Natural, black, blue, yellow, red, green, silver, etc.
Dimensions: Outer diameter 3,0 mm…28,0 mm x inner diameter 2,0 mm…24,0 mm.
Chemical Resistance: PA tubes have good chemical resistance against oils, hydraulic fluids, and fuels. Not suitable for chloride compounds.
